Blue Sea 2356100 - Water Resistant 100A Busbar w/Cover
|
Special Order
BC, Warehouse
"Special Order" items will take longer to process and ship then "Express" items. Typically takes no more then 14 days for delivery. For next day parts. Visit our express parts catalog Here. In Stock
|
$79.22
2356100 - Water Resistant 100A Busbar with Cover
Water-resistant bussing for harsh environments. Built with wing screws for toolless access.
Features:
- Accepts a wide range of wire sizes
- Includes 3 wire plugs to maintain a water-resistant rating if less than 4 wires are used
- Nests with other water-resistant 100A common busbars and ST-Blade water resistant fuse block for space-saving wiring
- Ideal for positive distribution and for the collection of negative or AC ground circuits
- Meets ABYC/USCG insulation requirements
- Tin-plated copper busses and fuse clips
- Includes four (4) write-on circuit labels
- Small format standard and custom labels are available
- Wing-screws designed for tool-free installation of cover to meet ABYC compliance
Technical Specifications:
- Cover - yes
- Maximum Voltage - 300V AC - 48V DC
- Terminal Stud - 1 x #10-32
- Continuous Rating - 100A AC or DC
- Bus Material - Tin-plated Copper
- Mounting Holes - Accepts 1/4" (6mm) screws
- Terminal Screws - 4 x # 8-32
- Wire Size - Input - (1) 8 AWG to 4 AWG
- Wire Size - Load - (4) 16 AWG to 10 AWG
In the Box:
- 2356100 Busbar
- Instruction Manual
*Sold as an Individual
Documentation
| Quick Guide | Download PDF |
|---|
