Cole Hersee M531Bp 2 Circuit Push Pull Switch - M-531-Bp - 12-M531Bpf1
|
Express
ON, Warehouse
"Express" items are automated and typically shipped out next available business day and delivered within 4 day. In Stock
|
$81.69
2 circuit. Normally off. 3 positions: Off - On #1 - On #2. Knob face dia: 3/4". Face nut, washer and hexnut. Permits two circuits (i.e., anchor and running lights) to be operated independently with one switch. Features non-corrosive construction. Gasket sealed case protects against moisture and dust. Brass mounting stem: 3/8" -32 x 1-1/4"L complete with chrome plated brass knob & face nut, washer, and hex nut for mounting. Mount in panels up to 1" thick. Rating 10A @ 12VDC. 6-36VDC. Brass housing. Boxed.
| Part #: | 12-M531BP |
| Manufacturer: | COLE HERSEE |
| Manufacturer Part #: | M-531-BP |
| UPC: | 632850496605 |
| Order In Multiples Of: | 1 |
| Terminals | 3 Screw |
| Positions | Off/On/On |
| Pkg. | Retail |
| Type | SPDT |
| Package | Retail |
