Mastervolt 44320605 Chargemaster Plus Czone® 3-Bank Battery Charger, 24V, 60 Amps - 44320605 - 469-44320605F1
|
Express
ON, Warehouse
"Express" items are automated and typically shipped out next available business day and delivered within 4 day. In Stock
|
$2,673.20
3-Step+ charge method optimum efficiency so your batteries will perform better and last much longer. Designed for versatility, it charges virtually any combination of three batteries in a fast and safe way and works anywhere in the world. The ChargeMaster Plus handles worldwide AC voltages and frequencies. Resisting large voltage fluctuations and high temperatures, it keeps working in harsh environments. Powerful ConnectionsIn modern applications, all components work together. CAN-based MasterBus enables the charger to communicate with displays, shunts and power systems including communication standards like CZone®, NMEA2000 and CANopen. The ChargeMaster Plus can operate as a power supply for delicate communication equipment, or during the construction phase of a boat. Multicharger with two outputs, one in/output, DC-DC converter, current limiter and VSRCombine Lithium Ion, Gel or AGM, and large or small battery banks on a single chargerCharges multiple batteries while underwaySafe Charge: quickly recognize the State of Charge for extended battery lifeVery wide operating range of 80-275V AC, 35-70 HzCompact, easy to connect and quick to install
| Part #: | 469-44320605 |
| Manufacturer: | MASTERVOLT |
| Manufacturer Part #: | 44320605 |
| Model Number: | 24/60-3 |
| UPC: | 816882022524 |
| Order In Multiples Of: | 1 |
| Volts | 24 |
| Banks | 3 |
| Amps | 60 |
| Size | 15.1" x 9.8" x 5" |
| Model | 24/60-3 |
| Charge Characteristic | IUoUo, automatic / 3-stage + for Gel / AGM / wet / Lithium Ion + a user-defined option |
| Communication(s) | MasterBus, CZone, NMEA |
| Cooling System | vario fan |
| Delay Lower Input Set Point | via automatic compensation or MasterShunt |
| Display Type | LED display |
| Galvanic Isolation | yes |
| Master Bus Compatible | yes |
| Nominal Input Voltage | 120/230V (80-275V) 50/60Hz |
| Nominal Output Voltage | 24 |
| Number of Battery Outlets | 3 (max.) |
| Overall Dimensions | 384 x 250 x 127 |
| Power Consumption | <2 mA (MasterBus out) |
| Power Factor Control | > 0.98 |
| Power Supply Mode | yes |
| Protection Degree | IP23, vertical mounting |
| Protections | over temperature, overload, short circuit, high / low battery voltage, ignition protection |
| Recommended Battery Capacity | 200-500 |
| Temperature Compensation | -60 mV/°C / -76 mV/°F incl. temperathoursensor |
| Temperature Range (Ambient Temp.) | -25 °C until 80 °C, afnemend > 40 |
| Total Charge Current | 60 A at 28.8 V. |
| Voltage | 24 |
| Weight | 5, 9 |
Variations
| 469-44310755 | Mastervolt 44310755 Chargemaster Plus CZone® 3-Bank Battery Charger, 12V, 75 Amps |
| 469-44311005 | Mastervolt 44311005 Chargemaster Plus CZone® 3-Bank Battery Charger, 12V, 100 Amps |
| 469-44320405 | Mastervolt 44320405 Chargemaster Plus CZone® 3-Bank Battery Charger, 24V, 40 Amps |
| 469-44321105 | Mastervolt 44321105 Chargemaster Plus CZone® 2-Bank Battery Charger, 24V, 110 Amps |
